Denon PMA-A110 Anniversary Edition Amplifier

110th Anniversary Edition Amplifier

The Denon limited series Anniversary Edition silver graphite PMA-A110 integrated amplifier delivers best in class audio performance for a best in class audio experience.

110 years defining audio excellence

For 110 years, Denon has delivered the most cutting-edge audio and video technical achievements.

Sound master inspired

The Denon sound master didn’t just tune this product, he obsessed over it.

High-power, integrated amplifier

160 watts of power delivers the most precise and powerful Denon sound.

Ultra AL32 processing

The PMA-A110 is equipped with Ultra AL32 Processing, the latest in analogue waveform reproduction technology from Denon.

TECHNICAL SPECIFICATIONS

Features

Channels             2

110th Anniversary Audio Tuning Yes

All black interior               Yes

Exclusive A110 speaker terminals              Yes

Aluminium Top Cover    Yes

Aluminium Feet Yes

Digital in: USB-B / optical / coaxial / USB-A           1 / 3 / 1 / No

Sample Rate digital In     192 kHz / 24-bit

USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6         <=DSD11.2

USB-B PCM sample rate 384 kHz / 32-bit

Quad DAC Configuration               Yes

DAC chip              4x PCM1795, Burr Brown Mono-Mode

Asynchronous mode rear USB    Yes

Bit-perfect transmission Yes

Ground isolator for DAC Mode operation              Yes

AL 32 Processing              ULTRA AL32

DAC Master Clock Design              Yes

Streaming audio from PC              Yes

Analogue Mode Yes

UHC-MOS single push pull circuit               7th Generation

LC mounted twin transformer    Yes

Wide range amplifier      Yes

High current dynamic power supply         Yes

Power amp discrete construction              Yes

Balance / Bass / Treble / Loudness           Yes / Yes / Yes / No

Others

Shottky diodes  Yes

Solid Heat Sinks Yes (BLACK)

Source Direct     Yes

Power Amp direct            Yes

Inputs Outputs

Audio Inputs      5

Digital in: USB-B / optical / coaxial / USB-A           1 / 3 / 1 / No

Phono Input: MM / MC  Yes / Yes

Audio Outputs   1

Power Amp Direct IN      Yes

Gold plated Cinch             Yes

Number of terminals      4

Remote Control Bus in / out        Yes

Remote Control Bus in / out        Yes

Specifications

Output power 8 Ohm (20 Hz – 20 kHz, T.H.D. 0.07%)         80 W

Output power 4 Ohm (1 kHz, T.H.D. 0.7%)             160 W

Total Harmonic Distortion            0.01%

Input Sensitivity: MM     2.5 mV / 47 kohm

Signal to Noise Ratio: MM/MC   89 dB / 74 dB

Signal to Noise Ratio: MM/MC   135 mV / 47 kohms

Signal to Noise Ratio: High level 110dB

Treble Control   ± 8 dB at 10 kHz

Bass Control       ± 8 dB at 100 Hz

General

Available colors: Premium Silver / Black  Silver Graphite

Metal Front Panel            Yes

Power Consumption in W             400

Standby Consumption in W          0.2

Auto Power Off Yes

Detachable Power Cable               Yes

Remote Control RC-1237

Remote Control Yes

Maximum Dimensions (W x D x H) in mm              434ｘ450ｘ182

Weight in kg       25

Carton Maximum Dimensions (W x D x H) in mm 573 x 533 x 317

Carton Weight (inc. product) in kg            29.8
