Features
- High capacity 200VA custom-made toroidal power transformer and power supply capacitors
- Improved all-aluminium casework and extruded front panel to control resonance and stray electro-magnetic fields
- High quality capacitors used in the signal path
- Uniquely tuned short signal and power supply path PCB
- Cascode circuitry utilised for improved power supply immunity
- Toshiba bipolar output transistors for dynamics and performance
- Separate pre-amp output
- Bi-wiring compatible
- 75 watts per channel into 8 Ohms
- Remote control
Specifications
- Power Output (Stereo) : 75 Watts per channel at 1KHz into 8 Ohms
- Input Sensitivity : 250mV
- Input Impedance : >14K Ohms, line input
- Pre-amplifier Output : gain + 18dB
- Frequency Response : 20Hz – 20Khz ± 0.5dB
- Total Harmonic Distortion : <0.05% at 1KHz, rated power
- Signal to Noise : >100dB, A weighted, ref. rated output
- Channel Separation :20Hz – 20KHz, >60dB
- Mains Supply : 220/240V, 50/60Hz (factory set)
- Power Consumption : <200VA (both channels driven, 8 Ohms load)
- Dimensions – H x W x D : 90mm x 440mm x 310mm
- Nett Weight (unpacked) : 7kg
- Gross Weight (packed) : 9kg
