Parasound Zpre3 Stereo Preamplifier
The Parasound Zpre3 is a compact stereo preamplifier, designed to deliver detailed sound and versatile control in a space-saving form. With both balanced XLR and unbalanced RCA inputs and outputs, the Zpre3 is ideal for custom installations or compact audio setups where sound quality and flexibility are essential.
- Design: Compact, rack-mountable form factor
- Inputs/Outputs: Balanced XLR, unbalanced RCA, and subwoofer output
- Features: IR remote control, 12V trigger, and loop output
- Applications: Ideal for custom installations and stereo systems where space is limited
The Parasound Zpre3 is the perfect preamplifier for high-quality stereo sound in a compact design, offering flexibility and powerful control for your audio setup.
Features of the Parasound Zpre3 Stereo Preamplifier
- Front panel LCD function display with dimming
- Automatic turn on volume memory
- Favorite volume memory with remote control button
- 2-way RS232 w/ exact volume control & feedback
- Discrete commands for all functions
- Rename inputs to match connected source
- 5 audio inputs including a front panel Aux input
- Bypass input integrates easily w/ a Sonos Connect® etc.
- Bass, treble and balance adjustments by remote control
- Variable and fixed stereo outputs
- Variable and fixed mono/subwoofer outputs
- 12dB auto gain offset at front panel AUX to match levels of other sources
- 12V trigger output and rear panel IR input
- Control4 Driver available
- Rack mount kit sold separately
Specifications of the Parasound Zpre3 Stereo Preamplifier | |
---|---|
Frequency Response | 10 Hz – 40 kHz, +0/-0.5 dB |
Total Harmonic Distortion (20 Hz – 20 kHz) | <0.015% |
Interchannel Crosstalk | 62 dB at 20 kHz |
Input Sensitivity | 250 mV = 1 V output Total gain = 12 dB (volume set to 100) Unity Gain = Volume set to 88 Maximum Output: 3.5 V |
Input Impedance | 24k Ω |
Output Impedance | 470 Ω |
S/N Ratio | >100 dB, input shorted, IHF A-weighted >90 dB, input shorted, unweighted |
DC Trigger Output | 12 Vdc, 50 mA |
AC Power Requirement | 5 Watts powered on 0.5 Watts in standby 100 – 250 VAC 50/60 Hz |
Dimensions | |
Width | 8.5″ (220 mm) |
Depth | 10″ (254 mm) 12″ (305 mm) with AC cord and cables connected |
Height | 2″ (51 mm) with feet 1.75″ (45 mm) without feet, 1U |
Weight | |
Net | 4.0 lbs (1.8 kg) |
Shipping | 7.0 lbs (3.1 kg) |
